171
range test, and to start the test mode.
6. Jumper (JP2 and JP3)
By default, the two jumper (JP2 and JP3) are not set.
Open position
JP2 (supervision): Active – please do not change this setting
JP3 (sensitivity): Set to “normal” level
Closed position
JP2 (supervision): Disabled – the alarm panel will transmit a supervision
error when controlling this sensor. Please do not use this setting
JP3 (sensitivity): Set to an increased level. Use this setting to increase the
sensitivity of the curtain motion detector.
7. Slot for the battery breaker
Connecting the curtain motion detector and putting it into operation
1. Remove the battery breaker from the corresponding slot of the curtain motion
detector to energise the devise.
2. The curtain motion detector will now enter a boot process. This initialization takes
approx. 30 seconds and the LED flashes during this time. Please wait until the LED
does not flash anymore.
3. Open the main menu of the alarm panel.
4. Open the menu “Sensors” “Add”.
5. Click “Start”.
6. Press the learn button of the curtain motion detector.
7. The alarm panel confirms the successful addition with a brief signal tone and
displays the curtain motion detector in the menu “Sensors” ”Add”. Click on
next to the listed sensor to finish the connection process.
Range test:
1. Open the alarm panel menu “Sensors” “Range” and press “Start”.
2. Press the learn button.
3. The sensor and the signal strength are indicated. The higher the indicated number
the better the reception (1-9).
Please note:
If the signal strength at the place of installation is below 4, we advise to use a wireless
repeater, since it is normal that the signal strength may fluctuate for 2-3 points, thus,
a signal loss is possible.
