230
The Power LED lights up blue and the keypad beeps twice. If the keypad returns
into standby mode before you completed your entries, the entries will be rejected. If
the outdoor keypad is supplied by a mains adapter, you can operate it directly
without prior activation.
o Blue LED on: keypad is activated
o Blue LED flashes: keypad is activated, battery is low
o Blue LED dimmed: keypad is in standby mode and operated by mains
adapter
o Off: keypad is in standby mode without connected mains adapter
o Orange LED: keypad is in learn mode
o Orange LED flashes: keypad is in learn mode, battery is low
Status LED (2):
Check the system status of the alarm panel by means of the keypad.
Enter a vail PIN code and press the button to check the current status of the
alarm panel. If you want to use your tag, press the status button and then hold
your tag to the tag reader.
o Red LED on: alarm panel in Arm mode
o Red LED flashes: alarm panel in Home mode
o Blue LED on: alarm panel in Disarm mode
o Blue LED flashes Error
No response from alarm panel
Incorrect PIN code
Switched to Home in while in arm mode
Forced arming despite reported problems by sensors
o If the status check does not work, the keypad was not added fast enough.
You need to add they keypad within 5 seconds after the alarm panel has
received the learn signal.
Please note:
You can only check the status of the area in which the outdoor keypad is
added.
Error LED (3):
o Orange LED on: Alarm in alarm panel memory!
o Orange LED flashes: system error, e.g.
SIM is missing
GSM not ready
Tampering contact open
Power failure of the alarm panel
Sensor out of range
Open sensor
Sensor battery too low
Activating the outdoor keypad V2
In order to activate the outdoor keypad while in battery mode, you need to touch
the sensitivity line of the outdoor keypad with two fingers. If you would press on
of the buttons in the middle before touching the sensitivity line, the keypad would
stay in standby mode.
