214323 355 Revision B
Figure 6.10: Every 100 Hours
C
ϭϬϯϵϴϱϬ
A - Knife Drive Box (Check Oil Level Between Lower Hole and End of Dipstick [B])
C - Main Drive Gearbox Oil Level. Refer to
MAINTENANCE AND SERVICING
