FUEL DELIVERY SYSTEMS AND FUEL PUMPS - 5A-390-823225--1 1096

Fuel System Components

Carburetor System

50830

a - Fuel Tank

b - Anti-Siphon Valve

c - Water Separating Fuel Filter

d - Fuel Pump

e - Carburetor

f - Fuel Filter

g - Vent Hose

h - Fuel Line

i - Sight Tube

1 - Boat Fuel System
