Mercury 305 CID - (Exploded View); Power Steering Pump and Components

9A-2 - POWER STEERING PUMP 90-823225--1 1096
Power Steering Pump and Components
(Exploded View)
72951
14
13
5
7
8
10
9
1
3
2
11
12
15
19
20
18
17
6
16
22
23
4
14
23
23
22
22
21
24
1 - Power Steering Pump Assembly
2 - Stud
3 - Cap
4 - Spacer
5 - Brace
6 - Spacer
7 - Lockwasher
8 - Bolt, Pump To Brace
9 - Pulley
10- Belt
11- O-Ring, High Pressure Hose Fitting
12- Hose, High Pressure (Fittings on Both Ends)
13- Hose, Pump To Fluid Cooler
14- Clamp
15- Hose, Control Valve To Fluid Cooler (Fitting On One End)
16- Mounting Bracket, Cast
17- Bolt
18- Spacer (Barrel Shaped)
19- Lockwasher
20- Nut (For Item 17)
21- Nut (For Item 21)
22- Lockwasher
23- Bolt To Cylinder Block
24- Power Steering Cooler
