90-823225--1 1096 WEBER 4 BARREL CARBURETOR - 5D-3
UNIT OF MEASUREMENT In. (mm)
ALL MEASUREMENTS ARE ± 1/64 In. (0.4 mm).
Carburetor Adjustment Specifications
Float Level 1-9/32 in. (33 mm)
Float Drop 2 in. (51 mm)
Pump Rod Hole Location Third Hole From End
Accelerator Pump 7/16 in. (11 mm)
1
Choke Pull-Off 15/64 in. (6 mm)
Choke Coil Rod Top Of Rod Even With Bottom Of Lever Hole
2
Preliminary Mixture Idle
Screw Setting
1-1/4 Turns
1
Measured from top of carburetor to bottom of S-link
2
Remove choke rod from lever hole. Choke held closed and choke rod pushed down with top edge of rod even
with bottom edge of hole.
