CLOSED COOLING MODELS - 6B-190-823225--1 1096
305/350 CID / 5.0L/ 5.7L
TORQUE SPECIFICATIONS
DESCRIPTION
Lb. In. Lb. Ft. N⋅m
Heat Exchanger End Caps 36-72 4-8
Seawater Pump Brace
Seawater Pump Bracket to Block
Seawater Pump Cover
Seawater Pump Mounting Nuts to Stamped Steel
Brackets
120 30 14
Thermostat Cover
Thru Hull Pickup Nut
Drain Plugs
Heat Exchanger Mounting Brackets Securely
Hose Clamps
LUBRICANTS, SEALERS AND ADHESIVES
DESCRIPTION
PART NUMBER
Quicksilver 2-4-C Marine Lubricant with Teflon 92-825407A3
Quicksilver Perfect Seal 92-34227-1
Quicksilver Liquid Neoprene 92-25711-2
Quicksilver Loctite Type 8831 92-823089-1
Loctite 514 9275505-1
Quicksilver Special Lubricant 101 92-13872A1
Loctite Pipe Sealant with Teflon Obtain Locally
SPECIFICATIONS
Cooling System Capacity With Coolant Flow
Thru Exhaust Manifold
20 (19)
Cooling System Capacity With Raw Water Flow
Thru Exhaust Manifold
Thermostat Stainless Steel 160° F (71 °C)
Thermostat Brass 140° F (67 °C)
Cap Pressure 14 PSI (97 kPa)
