Mercury 305 CID - Low Pressure Hose (Control Valve-To-Cooler)

9A-10 - POWER STEERING PUMP 90-823225--1 1096
Low Pressure Hose
(Control Valve-to-Cooler)
REMOVAL
NOTE: Catch fluid that drains from hose, cooler
and pump in a suitable container.
1. Loosen hose clamp and remove hose from fluid
cooler.
c
b
72588
a
Port Side Mounted Fluid Cooler
a - Fluid Cooler
b - Hose Clamp
c - Hose
74752
a
b
Rear Mounted Fluid Cooler
a - Fluid Cooler
b - Hose
2. Remove hose where routed and secured across
top of engine flywheel housing.
72853
a
Port Side Mounted Fluid Cooler Only
a - J-Clamps
3. Remove large fitting from control valve at tran-
som. Remove hose.
72026
a
Earlier Style Control Valve
a - Large Fitting
73786
a
Later Style Control Valve
a - Rear Fitting
