5B-4 - MERCARB 2 BARREL CARBURETOR 90-823225--1 1096
Identification
72680
33049565
2301
b
a
Carburetor Part Number Location
a - Part Number
b - Date Code
Data Code Explanation: Example 2301
First Figure is Year:
2 = 1992, 3 = 1993, etc.
Second Figure is Month:
2 = February, 3 = March, etc.
X = October, Y = November, Z = December
Third and Fourth Figures are Day of Month:
01 = First day, 02 = Second day, etc.
72779
a
Venturi Cluster Identification
a - Identification Number (See Specifications)
!
WARNING
Electrical, ignition and fuel system components
on your MerCruiser are designed and manufac-
tured to comply with U.S. Coast Guard Rules and
Regulations to minimize risks of fire and explo-
sion.
Use of replacement electrical, ignition or fuel
system components, which do not comply with
these rules and regulations, could result in a fire
or explosion hazard and should be avoided.
Important Service
Information
Flooding at Idle RPM
If your engine floods at idle RPM, check the following:
1. Problem in ignition system causing engine to run
rough.
2. Idle mixture screw adjusted incorrectly.
3. Bad needle and seat.
4. Incorrect float level drop.
Needle/Seat Change
If the preceding steps failed to correct the problem,
change the needle/seat to the other type. MerCarbs
are equipped with either the solid or the spring loaded
needle.
72290
b
a
Needle and Seat Assemblies
a - Spring Loaded Type Needle (Kit - 3302-9029)
b - Solid Type Needle (3302-9407)
To Next Page
