Mercury 305 CID - Page 781

CLOSED COOLING MODELS - 6B-790-823225--1 1096
72646
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
Two Piece Pump Assembly
1 - Screw (5)
2 - Washer (5)
3 - Cover
4 - Gasket
5 - Wear Plate (Outer)
6 - Gasket
7 - Plug
8 - Impeller
9 - Body
10- Gasket
11- Wear Plate (Inner)
12- O-Ring or Quad Ring
13- Oil Seal
14- Housing
15- Ball Bearing
16- Shaft
17- Ball Bearing
18- Snap Ring
19- Oil Seal
20- Hub
74577
1
2
3
4
5
6
7
8
9
10
11
12
13
14
One Piece Pump Assembly
1 - Screw (5)
2 - Washer (5)
3 - One Piece Body
4 - Quad Ring
5 - Impeller
6 - Wear Plate
7 - Oil Seal
8 - Housing
9 - Ball Bearing
10- Shaft
11- Ball Bearing
12- Snap Ring
13- Oil Seal
14- Hub
