Minebea Intec X3 User Manual

Field Size Function
Test_Active 1 bit The device executes the ADC test. The read weight
value is not the gross value, but the test value.
OutOfRange 1 bit Below zero or above max. (FSD).
Standstill 1 bit The scale is stable.
InsideZSR 1 bit The gross weight value is within the zero setting range.
CenterZero 1 bit The weight value is within center zero (0 ±0.25 d).
BelowZero 1 bit The weight value is negative (gross < 0 d).
Overload 1 bit The weight value has exceeded the measuring range.
No valid weight data is specified (gross > FSD+over-
load).
AboveMax 1 bit The weight value has exceeded the max. (FSD), but is
still within max. + permissible overload (gross ≤ FS-
D+overload).
ADUError 1 bit AD conversion error, see Chapter
12.2.5.2.
12.2.2 Reading and writing data with function numbers
12.2.2.1 Reading data
Procedure:
Action of the master Slave reaction
Write function number to
Read_Value_Select.
Write requested data in Read_Data (bytes
0-3).
Copy Read_Value_Select to
Read_Value_Selected.
Wait until Read_Value_Selected =
Read_Value_Select.
Read requested data in Read_Data (bytes
0-3).
12.2.2.2 Writing data
Procedure:
1. Write the function number as Read_Value_Select in byte 4 of the write window (e.g.,
9 = net weight).
2. Wait until Read_Value_Selected in byte 4 of the read window is equal to
Read_Value_Select of the write window.
The requested value is available in bytes 0-3.
1. Wait until Write_Active = 0 in the read window (slave is ready to receive new data).
2. Write value in bytes 0-3 of the write window.
12 Fieldbus interface X3 Process Indicator PR 5410
Minebea Intec EN-317
