Output range (MISO)
Byte Value Description
0 00 Gross weight - byte 0 (MSB)
1 00 Gross weight - byte 1
2 04 Gross weight - byte 2
3 D2 Gross weight - byte 3 (LSB)
4 08 Gross weight request detected.
5 Write
Active
Power
Fail
6 Cmd
Busy
Cmd
Error
Tare
Active
Cal
Active
Test
Active
7 OutOf
range
Stand-
still
Inside
ZSR
Center
Zero
Below
Zero
Over-
load
Above
Max
ADU
Error
In direct access, status bits are
independent of the write or read
request.
Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
The gross value (hex:000004D2 <=> 1234) can be read from bytes 0…3.
Negative values are output in the second complement.
12.2.7 Special note for DeviceNet and EtherNet IP
With these fieldbus types, the sequence of the bytes (only applicable for words and
individual bytes) is inverted.
With long words, this problem does not arise due to compensation by the firmware.
Sequence of data bytes 0…3:
Standard sequence Sequence for DeviceNet and
EtherNet-IP
Byte 0 Read data 0 (MSB) Byte 0 Read data 3 (LSB)
Byte 1 Read data 1 Byte 1 Read data 2
Byte 2 Read data 2 Byte 2 Read data 1
Byte 3 Read data 3 (LSB) Byte3 Read data 0 (MSB)
Consequently, the sequence on the PLC side must be changed when using the
"DeviceNet" and "EtherNet IP" fieldbus types.
12.3 Filling protocol (64-Byte) for the "EasyFill" application
The "EasyFill" application uses a 64-byte interface.
The 8-byte scale protocol for the "Standard" application is not available.
12.3.1 Write window (input area)
Data are transferred from the master (PLC) to the slave (PR 5410) in this window.
12.3.2 Read window (output area)
Data are transferred from the slave (PR 5410) to the master in this window.
The data required for monitoring and controlling filling does not fit in a 64-byte write
window. For this reason the system differentiates between system and material
