8.2.2 Configuring interaction mode using the front-panel keys
You can select between the following interaction modes:
- Remote control via OPC/ModBus and/or fieldbus
- VNC (Virtual Network Computing)
- Front-panel keys
Note:
See also Chapter
8.4.1.3.
8.2.3 Configuring digital inputs and outputs using the front-panel keys
Note:
See also Chapter 8.4.2.
Configuring digital inputs
1. Press .
SEtuP appears on the display.
2. Press OK.
The "Cd" calibration menu flashes.
Cd 000 appears on the display.
3. Press multiple times to select "IM 151."
4. Press OK.
IModE appears on the display.
5. Press OK.
??? appears on the display.
6. Press to select the desired mode.
7. Press "Exit" to exit the Setup menu.
1. Press .
SEtuP appears on the display.
2. Press OK.
The "Cd" calibration menu flashes.
Cd 000 appears on the display.
