4.6.8.2 Input
The Enable input for PR 5510/09 (PIN 25) can control the 23 outputs as DATA_IN.
As an output, data is "follow/hold/tristate" and its signal can be configured 5 V (TTL)/24 V
and active-high/active-low.
It is applied to pin 25 (DATA_IN) of the 26-pin connector and is effective only with
switches S101-1 = OFF and S101-2 = ON.
The switch settings can be found in the table in Chapter 4.6.9.
4.6.9 Switch settings
Switch S101
Input External supply S101
for
-1 -2 -3 -4 -5
DATA_IN 5 V active-
high
PIN 25 OFF ON ON ON ON or
OFF
DATA_IN 5 V active-
low
PIN 25 OFF ON ON OFF ON or
OFF
DATA_IN 24 V active-
high
PIN 25 OFF ON OFF ON ON or
OFF
DATA_IN 24 V active-
low
PIN 25 OFF ON OFF OFF ON or
OFF
activate internal free-wheel diode ON
do not activate internal free-wheel diode OFF
Switch S102
Input (PIN 25) Function for the
output data
S102
for
-1 -2 -3 -4 -5
DATA_IN follow hold PIN 2…24 OFF OFF ON ON or
OFF
ON or
OFF
DATA_IN tristate follow PIN 2…24 ON ON OFF ON or
OFF
ON or
OFF
DATA_IN tristate hold PIN 2…24 ON ON ON ON or
OFF
ON or
OFF
Input level
Input (PIN 25) External supply Voltage Current
DATA_IN 5 V active-high >3.1 V >0.5 mA
DATA_IN 5 V active-low <1.5 V <0.3 mA
DATA_IN 24 V active-high >16 V >1.0 mA
DATA_IN 24 V active-low <10 V <0.5 mA
4 Device installation X3 Process Indicator PR 5410
Minebea Intec EN-89
