Note:
* Err 31 appears on the display if the digit group for the IP address/mask is not
within 0–255, or is invalid.
7.5.11 Displaying the network address using the front-panel keys
The more significant part of the address* 255.255. (example) appears on the
display.
27. Press the cursor keys to select and set the desired numbers.
28. Once the last number is selected and set, press to set the less significant part of
the mask*.
255.255. (example) appears on the display.
29. Press the cursor keys to select and set the desired numbers.
30. Press OK.
nP 085 appears on the display.
31. Press OK.
EtAddr (hardware address/MAC ID) appears on the display.
32. Press OK.
The more significant part of the address* 00.90.6C. (example) appears on
the display.
33. Press to display the less significant part of the mask*.
70.49.45. (example) appears on the display.
34. Press OK.
SAVE appears on the display.
35. Press OK.
YES appears on the display.
36. Press OK.
SAVE ... appears on the display during the save process.
37. Press "Exit" to exit the Setup menu.
X3 Process Indicator PR 5410 7 Getting started
EN-144 Minebea Intec
