Page #54 background imageLoading...
Page #54 background image
4.5.8 Connection to relay PR 1626/6x
The connection is made via the connecting cable PR 6135/.. .
The internal load cell power supply (V+, V-) of the PR 5410 must not be connected.
Note:
Other connections are described in the PR 1626/6x instrument manual.
If PR 1626/61 (U
DC
= 7,5 V) is connected, the solder jumper (12) on the
PR 5410 mainboard should be opened (see Chapter
4.4.1). The sense voltage detection is
now switched.
NOTICE
Installation in the Ex zone
The screen of the load cell cable and the screen of the connecting cable must not be
connected inside the junction box, if connection of both ends is not permissible
according to the regulations for installation in the ex-zone.
X3 Process Indicator PR 5410 4 Device installation
EN-52 Minebea Intec
