— Limit 1…3 on Enter 0 – Max (maximum load); take unit from
calibration.
— Action Action, selection: no action, set marker 1…3, clr
(clear) marker 1…3
— Condition Condition, selection: see Chapter 7.18.7.
— Limit 1…3 off Enter 0 – Max (maximum load); take unit from
calibration.
— Action Action, selection: no action, set marker 1…3, clr
(clear) marker 1…3
— Condition Condition, selection: see Chapter 7.18.7.
— Output 1…3 Configure outputs, selection: see
Chapter 7.18.9.
— Input 1…3 on Configure inputs
— Action Action, selection: see Chapter 7.18.8.1.
— Condition Condition, selection: see Chapter 7.18.8.2.
— Input 1…3 off Configure inputs
— Action Action, selection: see Chapter 7.18.8.1.
— Condition Condition, selection: see Chapter 7.18.8.2.
— Analog mode Analog output parameter: Gross D08 = gross,
Net if tared D09 = Net if tared, Selected D11 =
value on the display, Transparent D30 =
Transparent, no output = analog output
unused, see Chapter 7.18.10.
— Analog range Output range: 0…20 mA, <4…20 mA>
— Output on error Output on error: 0 mA = set to 0 mA, <4 mA> =
set to 4 mA, 20 mA = set to 20 mA, hold = last
output value remains unchanged
— Output if <0 Output if <0: set 0 mA = 0 mA, set <4 mA> =
4 mA, set 20 mA = 20 mA, linear = goes below
4 mA down to the limit (with 4…20 mA),
absolute = absolute value
— Output if >Max Output if >Max: set 0 mA = 0 mA, set 4 mA =
4 mA, set <20> mA = 20 mA, linear = exceeds
20 mA up to the limit
— Weight at 0/4 mA Weight value for 0/4 mA output
— Weight at 20 mA Weight value for 20 mA output
7.13.9 Digital I/O parameters
Note:
This menu item is only available if under
-[Operating parameter]- [Application]
"Standard" has been selected.
7.13.10 Analog output parameter
7 Getting started X3 Process Indicator PR 5410
Minebea Intec EN-163
