Minebea Intec X3 User Manual

- Connect the screens.
- Establish grounding/equipotential bonding between devices/system components.
4.3 EMC-compliant installation
4.3.1 Connecting the screens
The screen for the D-Sub connector must be connected as described in Chapter
4.6.1.2.
The screens for the connecting cable/load cell cable must be connected to the grounding
terminal on the back of the device.
4.3.2 Connecting the equipotential bonding conductor
The equipotential bonding conductor must be connected to the grounding terminal on
the back of the device.
4.4 Hardware construction
The overall electronics is installed on the following units:
- Mainboard
- Display board
4.4.1 Main board
The main board provides the slots for the
- Interface cards (accessories; see Chapter
4.6)
- Fieldbus card (accessories; see Chapter 4.6)
The lithium battery (5, under the cover for the power supply) is always activated and
powers the calendar/clock module.
4 Device installation X3 Process Indicator PR 5410
Minebea Intec EN-33
