Note:
After installation/modification, the plug-in cards are detected automatically.
The installed plug-in cards can be displayed via
- [Show HW-Slots]; see
Chapter 7.19.3.
4.6.1.1 Installing plug-in cards
Note:
The ribbon cables are plugged into the ports (slot 1…2, 4) on the main board.
The cables are coded to protect against incorrect polarity.
A maximum of 2 cards can be mounted. Accordingly, there are two openings in the back
panel for the card support plates.
Procedure:
4.6.1.2 Installation of a cable in the D-sub connector
The connections on the back wall are plugs. The wires must be kept as short as possible
leading to the terminals. The plug housings are conductive (metallic) and thus also part of
the screen. They must be screwed correctly to the back wall.
NOTICE
Material damage is possible.
The cable screen must be connected to the metal housing on both ends of the cable.
1. Open the device (see Chapter
2.4.2).
2. Remove the corresponding dummy plates on the rear panel (2× M3) and replace them
with the support plates for the plug-in cards.
3. Insert the ribbon cables into the appropriate ports on the main board.
4. Close the device again.
X3 Process Indicator PR 5410 4 Device installation
EN-58 Minebea Intec
