3.3.2 Dimensions
Front view Side view
all dimensions in mm
all dimensions in mm
Back view
all dimensions in mm
3.3.3 Control panel cut-out
The control panel cut-out must be made before installing the device.
all dimensions in mm
X3 Process Indicator PR 5410 3 Device description
EN-18 Minebea Intec
