Enter the minimum load:
0 d…<50 d>…999999 d
— Range mode Range selection: <Single range>, Multiple
range, Multi-interval
See also Chapter FEHLER andFEHLER.
— Range limit 1 Inputrange limit 1: In weight, unit as for Max,
transition from low to medium scale interval
Only for [Multiple range] or [Multi-interval]!
— Range limit 2 Inputrange limit 2: In weight, unit as for Max,
transition from low to medium scale interval
Only for [Multiple range] or [Multi-interval]!
— LC name Give each load cell a name.
— LC 1…n Load cell 1…n, e.g.: PR6203-xx
Input max. 20 alphanumeric characters.
— Default Settings are reset to factory settings.
— Service Service function for load cells: Deactivating/
activating the load cell.
— LC 1…n Load cell 1…n
Select the defective load cell and reset the ☑
box to ☐.
Select the new (replaced) load cell and set the
box ☑.
— Accept Accept:
After deactivation, the simulation of the
deactivated load cell is started.
After activation of the replaced load cell, the
search process is started.
— Assign (CAL switch closed)
— View Item number, serial number and current weight
of connected load cells are displayed.
— Info The data from the selected load cell is
displayed.
— by name Change the display of [ID] (LC 1…n + serial
number) according to [by name] of the load
cells; only possible if a load cell name has been
assigned.
— LC name Change the display of [ID] (LC 1…n + serial
number) according to [by name] of the load
cells; only possible if a load cell name has been
assigned.
— Service The service window for the load cells is
displayed. No change is possible!
7.13.8 Limit parameter
Note:
This menu item is only available if under
-[Operating parameter]- [Application]
"Standard" has been selected.
X3 Process Indicator PR 5410 7 Getting started
EN-162 Minebea Intec
