An error message appears if the digit group for the IP address/mask is not within 0–255,
or is invalid.
7.5.10 Entering the network address using the front-panel keys
Note:
A new address may be assigned by the server in the event of a restart.
SAVE ... appears on the display during the save process.
21. Press "Exit" to exit the Setup menu.
1. Press .
SEtuP appears on the display.
2. Press OK.
The "Cd" calibration menu flashes.
Cd 000 appears on the display.
3. Press multiple times to select "nP 080."
4. Press OK.
dHCP (DHCP) appears on the display.
5. Press OK.
DHCP is activated. The network address is assigned automatically.
If DHCP is not activated ("oFF"), the addresses must be entered manually.
on appears on the display.
6. Press OK.
nP 081 appears on the display.
7. Press OK.
IP.Addr appears on the display.
8. Press OK.
The more significant part of the address* 172.024. (example) appears on the
display.
9. If DHCP "oFF" is selected: Press the cursor keys to select and set the desired numbers.
10. Once the last number is selected and set, press to set the less significant part of
the address*.
X3 Process Indicator PR 5410 7 Getting started
EN-142 Minebea Intec
