With legal-for-trade applications, the CAL switch must be sealed in the closed position.
Note:
If the weighing electronics board has been changed after calibration or the device is not
calibrated the weight value display will show "Error 15" if the CAL switch is closed.
The position of the CAL switch is shown with VNC/WEB browser under – [Show
status]:
[opened] = opened, no write protection.
[closed] = closed, write protection is active.
7.1.3.2 Factory settings
Calibration data <default> Calibration parameters <default>
Full Scale (FSD) (Max) <3000> <k-
g>
Measurement time <160> ms
Scale interval <1> Digital filter <off>
Dead load <0.000000> mV/V Test mode <absolute>
SPAN <1.000000> mV/V W&M* <none>
Standstill time <0.5> s
Standstill range <1.00> d
Zero range <50.00> d
Zerotrack range <0.25> d
Zerotrack step width <0.25> d
Overload (range over Max.) <9> d
Min <20> d
* The parameter [W&M] must be selected before entering the calibration data or must be
set to [none] = "off", see Chapter
7.14.15.
7.1.4 Restart
The PR 5410 is restarted using the front-panel keys.
7 Getting started X3 Process Indicator PR 5410
Minebea Intec EN-123
