12.2.5 Function numbers
Function numbers are written to MOSI by the master (SPS) and reflected in MISO by the
PR 5410.
- Funktionsnummer 0: I/O status bits (read), see Chapter 12.2.5.1
- Function number 1: scale status (read), see Chapter 12.2.5.2
- Function number 4: calibration information, error byte (read), see Chapter 12.2.5.5
- Function number 5: device type and software version (read), see Chapter 12.2.5.6
- Function number 6: serial number of the weighing point (read), see Chapter 12.2.5.7
- Function numbers 8 to 15: weight data (read), see Chapter 12.2.5.9
- Function numbers 24 to 29: Limit value (read/write), see Chapter 12.2.5.10
- Function numbers 30, 31: values of the current weighing point (read), see
Chapter 12.2.5.11
- Function numbers 80 to 89: state-controlled action bits (write), see Chapter 12.2.5.12
- Function numbers 112 to 119; 121: transition-controlled action bits (write), see
Chapter 12.2.5.13
12.2.5.1 Function number 0: I/O status bits (read)
Dynamic status
Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
Byte 0 Input 3 Input 2 Input 1
Byte 1 Output 3 Output 2 Output 1
Byte 2 Limit 3 Limit 2 Limit 1
Byte 3
12.2.5.2 Function number 1: scale status (read)
Dynamic status
Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
Byte 0 OutOf
Range
Standstill Inside ZSR Center
Zero
Below
Zero
Overload Above Max ADU Error
Byte 1 E9 E6 E1 E3 E7
Byte 2 PowerFail Action
Active
CmdError
Byte 3 Tare Active Cal
Changed
Test Active
Note:
Byte 0 corresponds to byte 7 in the output area. Weight error in byte 1, see table in
Chapter
16.1.
X3 Process Indicator PR 5410 12 Fieldbus interface
EN-320 Minebea Intec
