12.2.5.6 Function number 5: device type and software version (read)
Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
Byte 0 TYPE MSB
Byte 1 TYPE LSB
Byte 2 MAINVERSION
Byte 3 SUBVERSION
12.2.5.7 Function number 6: serial number of the weighing point (read)
Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
Byte 0 Serial number MSB
Byte 1 Serial number
Byte 2 Serial number
Byte 3 Serial number LSB
e.g.: 148388723 = 08D83B73
hex
12.2.5.8 Function number 7: For internal use only.
12.2.5.9 Function number 8 to 22: weight data (read)
The gross, net, and tare weight are stored as a DINT fix point. The real data value is
derived from DINT and EXPO as follows:
Value
Real
= reading
DINT
× 10
(-EXPO)
Function number 8 Current gross value
Function number 9 Current net value, if tared; otherwise gross
Function number 10 Current tare value, if tared; otherwise 0
Function number 11 Current gross/net weight selected with bit 72.
Function number 12 Current gross value in internal resolution (1/100d)
Function number 13 Current tare value in internal resolution (1/100d)
Function number 14 Max (Full scale deflection)
Function number 15 Reserved for internal use.
Function number 16 Print gross weight/enter in Alibi memory.
Function number 17 Print net weight/enter in Alibi memory.
Function number 18 Print tare weight/enter in Alibi memory.
Function number 19 Print sequence number/enter in Alibi memory.
Function number 20 Output value (BCD format)
Function number 21 Print date/enter in Alibi memory (BCD format).
Function number 22 Print time/enter in Alibi memory (BCD format).
12 Fieldbus interface X3 Process Indicator PR 5410
Minebea Intec EN-323
