12.2.5.3 Function number 2: For internal use only.
12.2.5.4 Function number 3: For internal use only.
12.2.5.5 Function number 4: calibration information, error byte (read)
Byte Description
0: EXPO One byte for the position of the decimal point; content in decimal
form: 0 to 255.
0 = 000000
1 = 00000.0
2 = 0000.00
3 = 000.000
4 = 00.0000
5 = 0.00000
1: UNIT One byte for the weight unit; content in decimal form: 0 to 255
2 = g (grams)
3 = kg (kilograms)
4 = t (tons)
5 = lb (pounds)
2: STEP One byte for the scale interval; content in decimal form: 0 to 255
1 = scale interval "1"
2 = scale interval "2"
5 = scale interval "5"
10 = scale interval "10"
20 = scale interval "20"
50 = scale interval "50"
3: LASTERROR Last error byte; see also CmdError bit, number of LASTERROR:
8 = no standstill was achieved (e.g., when taring).
13 = zero setting is not possible. The scale has been tared.
18 = negative weight value when taring and W&M mode on.
147 = no zero setting; weight not within zero setting range.
255 = general command error
Note:
Other error nos are possible.
X3 Process Indicator PR 5410 12 Fieldbus interface
EN-322 Minebea Intec
