4.5.4 Connecting between 2 and8 load cells (650 ) using a 6-wire connection cable
Connections are made via cable junction box PR 6130/.. using connection cable PR 6135/..
or PR 6136/... .
Load cell supply circuit
- Load resistance of load cell circuit ≥75 , e.g., 8 load cells of 650 each
- The supply voltage is fixed at U
DC
= 12 V and protected against short circuits.
For further technical data, see Chapter
17.5.1.
Note:
If hum interference occurs, the cable screens should only be connected on one side.
Depending on the design of the cable junction box used, either the jumper J3 must be
removed or the cable screens must be disconnected from the terminal contacts
highlighted in yellow.
X3 Process Indicator PR 5410 4 Device installation
EN-48 Minebea Intec
