7.17.5 Assign load cells
The load cells (serial number) can be assigned to the place of installation in this menu.
This is important for correcting the dead load (distribution to the individual load cells), for
corner correction and in the event of load cell replacement.
An example of a possible assignment is shown below.
Note:
The assignment from the installation should be documented in the case of load cells
being replaced.
With load cells PR 6221 With load cells Inteco®
The menu is accessed via - [Weighing point] - [Weighing point A] - [Assign] - [View] .
The load cells are assigned by placing minimum weights on the scale (approx. 50 kg).
As soon as the device detects the weight change, the corresponding line is selected.
1. Unload the scale.
2. Press the [Assign] softkey.
You are prompted to confirm.
3. Press the [Continue] softkey to reset the dead load information and start the
assignment procedure.
4. Press the [Cancel] softkey to not start the assignment.
5. Place the weight on the corner/load cell which will be assigned no. 1 later.
6. Confirm the assignment of the first load cell by selecting .
The future LC no. is shown at the far right of the line.
7. Remove the weight.
7 Getting started X3 Process Indicator PR 5410
Minebea Intec EN-217
