— Filling
— Material ID Material identification
Selection: ID 1…10
— Material name Material name
Input: max. 18 alphanumeric characters
— Set point Set point
Input: weight; adopt unit from the calibration.
— Preset Preset point for switching from coarse flow to
fine flow. Input: weight; adopt unit from the
calibration.
— Overshoot (OVS) Material overshoot
Input: Weight; adopt unit from the calibration.
— +/- tolerance Tolerance above/below set point
Input: tolerance values; adopt unit from the
calibration.
— Calming time Calming time
Input: in ms
— Start Start filling.
— Stop Stop filling.
— Restart Restart filling.
— Abort Abort filling.
6 "EasyFill" application
6.1 Functions
6.1.1 General information
The "EasyFill" application is used for the batching of single components.
The application allows for quick and reliable filling and emptying of vessels.
The dosing process can be started, stopped, interrupted and restarted via the front-panel
keys, VNC user interface, digital inputs, OPC/Modbus and field bus (except for CC link).
6.1.2 Display functions
- Display of gross, net or tare weight
- Tare/reset tare
- Set gross to zero
- Print weight
- Display of weight values or remote display
- Functions via digital inputs and outputs
- Information interchange via serial I/O, fieldbus and network
6.1.3 Filling mode
The "EasyFill" application supports the following filling modes:
- Net filling "B1"
- Net discharge "B4"
6.2 Application menu [Start]
X3 Process Indicator PR 5410 6 "EasyFill" application
EN-120 Minebea Intec
