— HW address MAC-ID, display: e.g.: 00:90:6C:31:1F:55
— Hostname Unique device name, input: 2…24
alphanumerical characters
— Use DHCP Check the ☑ box to activate DHCP.
— IP address IP address, display: network address assigned
by the server
— Subnet mask Subnet mask, display: Mask for valid IP address
range
— Default gateway Standard gateway, display: IP number for
gateway
— Remote access Remote access to VNC client
— VNC client Access restriction, Input: authorized client for
instrument operation
— Weighing point A Selection: Internal A, xBPI-scale, Pendeo Load
Cells, Connexx Load Cells
— Calib Calibration, selected "Internal A:" New, Modify,
Param, see Chapter 7.13.7.1.
— Setup Setup, "xBPI-Scale" selected: Calibration,
Configuration, Select, Show device info, see
Chapter 7.13.7.2.
— Config Configuration, "xBPI-Scale" selected: Type,
W&M, Tare timeout, Serial number, SBN
Address, see Chapter 7.13.7.2.
— Param Configuration, "xBPI-Scale" selected: Assigned
to, Baudrate, Bits, Parity, Stopbits, see
Chapter 7.13.7.2
— Assign Assign, "Pendeo Load Cells" selected: Search,
View, Calib, LC name, Service, see
Chapter 7.13.7.3/7.13.7.4.
— Calib Calibration of the weighing electronics
— New Query window for new calibration: Reset Span
and dead load
Contin, Cancel
— Max Input of the maximum load:
0.00001…<3000>…999999 <kg>, t, lb, oz, g,
mg
— Scale interval Input of the scale interval: <1>, 2, 5, 10, 20, 50
— Dead load at <0.000000 mV/V> or [by load]
[by load]: 0.00001…999999 <kg>, t, lb, oz, g,
mg
— Max at <1.000000 mV/V> or [by load]
7.13.5 Fieldbus parameter
7.13.6 Network parameter
7.13.7 Weighing points
7.13.7.1 "Internal A" weighing point
X3 Process Indicator PR 5410 7 Getting started
EN-154 Minebea Intec
