— Set SBN The xBPI address of the interface has to be <0
>, because there is no bus operation.
— Config Configuration of the xBPI scale
— W&M Selection legal-for-trade mode: <none>, OIML,
NSC, NTEP
— Tare timeout Timeout due to instability: 0.1 s…<2.0 s>…25 s
— Serial number <0>, if >0 the serial number will be checked (at
legal-for trade scale)
— SBN Address <0> no bus operation.
— Param parameter settings of the xBPI scale
— Assigned to Assigned to: xBPI-Port 1
— Baudrate Select transmission speed: <9600>, 19200
— Parity odd (odd parity)
— Stop bits Selection: <1>, 2
— Assign Assignment of the Pendeo scale
Type, number of load cells, serial number of
each load cell and weighing point serial number
(when it was already calculated) are displayed
(when "Search" was executed).
— Search Search connected load cells.
Search for a new network and reset the load cell
data to the factory settings.
— View Serial number and current weigh of connected
load cells are displayed.
— Info The data for the selected Loading cell are
displayed.
— Assign load cells (serial number) are assigned to the
installation site.
— Calib Serial number and current weigh of connected
load cells are displayed.
— New Query window for new calibration: Corner
correction will be reset Yes, No
— Local gravity Enter the on-site gravitational acceleration
(Standard: Hamburg 9.81379 m/s
2
)
— Number of
platforms
Only for Pendeo Truck: Only shown if the
number of load cells is equal to 8.
— Number of
vessel feet
Only for Pendeo process: Enter the number.
— Max Enter maximum load:
0.000010…<3000>…9999998 <kg>, t, lb, g,
mg, oz
— Scale interval Enter verification interval (1 d): <1>, 2, 5, 10, 20,
50 displayed according to the decimal places at
Max and the weight unit.
— Dead load dead load: Weight of the empty scale
— CAL weight Enter CAL weight: 0.000010…9999998 <kg>, t,
lb, g, mg, oz
7.13.7.3 "Pendeo® Truck/Process" weighing point
X3 Process Indicator PR 5410 7 Getting started
EN-158 Minebea Intec
