Note:
For further information, see the installation manuals relating to the load cells and
junction boxes.
4.6.4 CANopen interface
The CANopen interface card has the type designation PR 5510/05.
Only one PR 5510/05 card can be plugged into "Slot 1" or "Slot 2".
The CANopen interface card is supported by software version 4.60.
This is used to connect the Connexx modules via a CAN bus.
The interface can supply a maximum of 4 Connexx modules via the D-Sub connection. For
more than 4 Connexx modules, an external power supply is required that can also be
connected to this interface card.
X3 Process Indicator PR 5410 4 Device installation
EN-70 Minebea Intec
