Minebea Intec X3 User Manual

— Configuration
— Configuration mode Configure the mode
— Dosing mode Filling mode
Selection: Net filling (B1), Net Discharge (B4)
— Interaction mode Interaction mode
Selection: Remote proc. control, VNC, Front
keys
— Print Print configuration.
— Configuration digital I/Os
— Configuration digital
inputs
Configure digital inputs
— 1…3: SPM address
%MX
Input: SPM address, see Chapter 13.4
— Print Print configuration.
— Configuration digital
outputs
Configure digital outputs
— 1…3: SPM address
%MX
Input: SPM address, see Chapter 13.4
— Print Print configuration.
— Configuration material
— Material ID Material identification
Selection: ID 1…10
— Material name Material name
Input: max. 18 alphanumeric characters
— Set point Set point
Input: weight; adopt unit from the calibration.
— Preset Preset point for switching from coarse flow to
fine flow. Input: weight; adopt unit from the
calibration.
— Overshoot (OVS) Material overshoot
Input: weight; adopt unit from the calibration.
— +/- tolerance Tolerance above/below set point
Input: tolerance values; adopt unit from the
calibration.
— Calming time Calming time
Input: in ms
— Default Reset values to 0.
— Print all Print all ID entries.
— Print Print selected ID entry.
— Configuration printing
— Number printouts Number of printouts
Input: 1…10
— Sequence number Sequence number, see Chapter 8.4.4.
— Use NLE Use NLE
Check the ☑ box to activate printing with
NiceLabelExpress.
— Line 1…6 Line 1…6
Selection: see Chapter 8.4.4
— Print Print configuration.
6 "EasyFill" application X3 Process Indicator PR 5410
Minebea Intec EN-121
