16-7. Weld commands（For TIG welding）
16-7-1. ACFRQ
Format
ACFRQ = [Frequency]
Function It sets AC TIG frequency. Frequency Frequency [50 – 400] Hz
Condition
Lock condition Arc lock (Internal execution).
Syntax check None.
Example
Set the AC TIG frequency to 70Hz.
ACFRQ=70
The same command in
conventional models
16-7-2. ARC-SET_TIG
Format
ARC-SET_TIG Ib=[Base Amp] Ip=[Peak Amp] WF=[Filler spd] FRQ=[Frequency] S=[Speed]
Function It specifies TIG welding conditions. Base Amp Base amperage. [1 – 999] A
Condition Weld package. Peak Amp Peak amperage. [1 – 999] A
Lock condition Arc lock (Internal execution, specify values.) Filler spd Filler speed. [0.00 - 99.99]
Syntax check None. Frequency Frequency. [0.0 - 500.0] Hz
Example Speed Welding speed. [0.01 - 120.00]
m/min
Set parameters for TIG welding operation whose
base amperage is 120A, peak amperage is 180
A, filler speed is 10, frequency is 0.5 Hz and
speed is 0.50 m/min.
ARC-SET_TIG Ib=120 Ip=180 WF=10
FRQ=0.5 S=0.50
The same command in
conventional models
AJO(TIG)
16-7-3. CHKVOLT
Format
CHKVOLT = [Detection voltage for electrode short]
Function It sets detection voltage for electrode short. Detection volt. Detection volt. [0.0 - 15.0] V
Condition
Lock condition Arc lock (Internal execution).
Syntax check None.
Example Set the detection voltage to 5.0V..
CHKVOLT = 5.0
The same command in
conventional models
16-7-4. CLEAN
Format CLEAN = [Value]
Function It sets cleaning width. Value
EN ratio [50 – 90] ％
Condition
Lock condition Arc lock (Internal execution).
Syntax check None.
Example Set the cleaning width to 70%.
CLEAN = 70
The same command in
conventional models
