Panasonic VR2 Series - Pduty_Tig; Pfrq_Tig; Tigslp; Wfdslp

16-28
16-7-10. PDUTY_TIG
Format
PDUTY_TIG [Pulse width]
Function It adjusts pulse width for TIG welding. Pulse width Pulse width. [5 - 95] %
Condition Weld package.
Lock condition Arc lock (Internal execution).
Syntax check None.
Example Set pulse width to 50%.
PDUTY_TIG 50％
The same command in
conventional models
PDUTY
16-7-11. PFRQ_TIG
Format
PFRQ_TIG [Pulse frequency]
Function It sets pulse frequency for TIG welding
Condition Weld package.
Pulse
frequency
Lock condition Arc lock (Internal execution).
Syntax check None.
[0 and 0.8 - 500.0] Hz for the
digital TIG specifications.
[0 to 49.9] Hz for the analog type
welding machines.
Example Set the pulse frequency to 10 Hz.
PFRQ_TIG 10.0
The same command in
conventional models
PFRQ
16-7-12. TIGSLP
Format
TIGSLP Ib= [Base amp] Ip=［Peak amp］ [Slope range]=[Value]
Function It slopes welding amperage. Base amp Final slope base amp. [1 – 999] A
Condition Weld package. Peak amp Final slope peak amp. [1 – 999] A
Lock condition Arc lock (Internal execution). Slope range Slope range definition
T=: Time range
D=: Distance range
NEXT: To the next step
Syntax check None. Value T=: Time [0.01 - 999.99] s
D=: Distance [0.01 - 999.99] mm
NEXT: No value
Example
TIGSLP Ib= 30 Ip=60 NEXT
16-7-13. WFDSLP
Format
WFDSLP WFED= [Filler wire speed] [Slope range]=[Value]
Function It slopes filler wire feed speed. Final wire feed speed
Condition Weld package.
Filler wire
speed
[0 - 15.00] m/min
Lock condition Arc lock (Internal execution). Slope range Slope range definition
T=: Time range
D=: Distance range
NEXT: To the next step
Syntax check None. Value T=: Time [0.01 - 999.99] s
D=: Distance [0.01 - 999.99] mm
NEXT: No value
Example
WFDSLP WFED= 10 NEXT
