15-4. Welder data settings (Powder plasma welding)
This section explains welder data settings for Panasonic powder plasma welding machine.
Click
>>
Set
>>
Arc welding
>>
(
User specified
welder name
1)
[Over write] Check this item to edit the current settings.
[Backup the current Welder and add a new Welder] Check
this item to make a copy of the currently defined welder to add
another welder. When you select this item, you must specify
the name of the welder you want to make a copy of. ([Name
of the backup Welder])
YP-200PB1
15-4-1. Weld conditions
Powder plasma welding conditions are set.
Weld
condition
15-4-2. Adjust value
Difference between setting data and actual measured value are compensated.
Adjust value
[Current]: Compensation for current , (-50〜+50)A
[FRQ]: Compensation for pulse frequency, (-5.0〜+5.0)Hz
[Powder]: Compensation for powder feed, (-50〜+50)%
