VTrak E-Class Product Manual
84
Managing Fibre Channel Connections
This feature pertains to VTrak Fibre Channel models. Functions include:
• Viewing Fibre Channel Node Information (page 84)
• Viewing Fibre Channel Port Settings (page 84)
• Making Fibre Channel Port Settings (page 85)
• Viewing Fibre Channel Port Statistics (page 86)
• Viewing SFP Information (page 87)
• Viewing Fibre Channel Logged-in Devices (page 88)
• Viewing Fibre Channel Initiators (page 88)
Viewing Fibre Channel Node Information
To view Fibre Channel node information:
1. Click the Subsystem icon in Tree View.
2. Click the Administrative Tools icon.
3. Click the Fibre Channel Management icon.
4. Click the Node tab in Management View.
The current node (data port) settings the Controller are shown, including:
• WWNN – World Wide Node Name
• Supported Features – Class of service
• Maximum Frame Size – 2048 bits
• Supported Speeds – 4 Gb/s, 2Gb/s, or 1 Gb/s
Viewing Fibre Channel Port Settings
To view the current Fibre Channel port settings:
1. Click the Subsystem icon in Tree View.
2. Click the Administrative Tools icon.
3. Click the Fibre Channel Management icon.
4. Click the Port tab in Management View
The current data port settings the Controller are shown, including:
• State – Online, Offline, Unknown
• Port Identifier – A hexadecimal name for this port
• Topology Attached – See the table on page 86
• WWNN – World Wide Node Name
• WWPN – World Wide Port Name
