VTrak E-Class Product Manual
64
Viewing Subsystem Information
To view information about a subsystem, click the Subsystem icon in Tree
View. The Information tab in Management View displays the subsystem
information.
Saving a System Service Report
To save a System Service Report as a compressed HTML file:
1. In Tree View, click the Subsystem icon.
2. On the Information tab, click the Save button.
3. In the dialog box, click the Save File option, then click the OK button.
The service report is saved to the Host PC from which you access WebPAM
PROe. The file name includes subsysteminfo, the date, and html.
Setting an Alias for the Subsystem
An alias is optional. To set an alias for this subsystem:
1. In Tree View, click the Subsystem icon.
2. In Management View, click the Settings tab.
3. Enter a name into the Alias field.
Maximum of 48 characters. Use letters, numbers, space between words,
and underscore.
4. Click the Submit button.
Setting Redundancy for the Subsystem
To set redundancy for this subsystem:
1. In Tree View, click the Subsystem icon.
2. In Management View, click the Settings tab.
3. In the Redundancy Type dropdown menu, choose:
• Active-Active – Both RAID controllers are active and can share the
load
• Active-Standby – One RAID controller is in standby mode and goes
active if the other fails
4. Click the Submit button.
If you change Redundancy Type, be sure both controllers are properly installed in
the subsystem before you restart.
If your subsystem has dual controllers and they are set to Active-Active, you can
use the LUN Affinity feature. See “Making Controller Settings” on page 122.
