Example 1: If you connect the VTrak to a Fibre Channel switch and choose
NL-Port topology, you will create a Public Loop attached topology.
Example 2: If you have a Point to Point attached topology, you made a
direct connection (no switch) and selected N-port topology.
Viewing Fibre Channel Port Statistics
To view statistics for the Fibre Channel ports:
1. Click the Subsystem icon in Tree View.
2. Click the Administrative Tools icon.
3. Click the Fibre Channel Management icon.
4. Click the Statistic tab in Management View.
The statistics for all Fibre Channel ports are shown.
Property Definitions
Definitions of the properties for which statistical information is reported appears in
the list below.
• Time Since Last Reset – Time in minutes since the system has been
running.
• Number of Frames Sent – Number of frames sent since last reset.
• Number of Frames Received – Number of frames received since last reset.
• Number of Words Sent – Number of words sent since last reset.
• Number of Words Received – Number of words received since last reset.
• LIP Count – Loop Initialization Primitive Sequence. This primitive sequence
applies only to the arbitrated loop topology. It is transmitted by an L_Port to
initialize or re-initialize the loop.
Fibre Channel Attached Topology
Configured Topology
Connection Type N-Port NL-Port
Switch Fabric Direct Public Loop
Direct Point to Point Private Loop
Note
In some cases, HBA settings to N-Port only work if connected to
the switch. Refer to your HBA manual for more information.
