Promise Technology VTRAK E610f User Manual

Chapter 4: Management with WebPAM PROe
85
• Fabric WWNN – World Wide Node Name (appears when connected to
a switch)
• Fabric WWPN – World Wide Port Name (appears when connected to a
switch)
• Current Speed – 4 Gb/s, 2 Gb/s, or 1 Gb/s
• Link Type – Long-wave laser, short-wave laser or electrical
• Link Speed* – 4 Gb/s, 2 Gb/s, 1 Gb/s, or Auto
• Topology* – NL-Port, N-Port, or Auto
• Hard ALPA* – Address can be 0 to 254. 255 means this feature is
disabled
• Alias WWPN
* Denotes items that you can change under Port Settings, below.
Making Fibre Channel Port Settings
To make Fibre Channel port settings:
1. Click the Subsystem icon in Tree View.
2. Click the Administrative Tools icon.
3. Click the Fibre Channel Management icon.
4. Click the Port tab in Management View
5. Click the Port1 or Port2 link in Management View.
6. Make the settings appropriate to your system. See “Port Setting Information”
on page 85.
• Configured Link Speed – 4 Gb/s, 2 Gb/s, 1 Gb/s or Auto (self-setting)
• Configured Topology – N-Port (Point-to-Point), NL Port (Arbitrated
Loop) or Auto (self-setting)
• Hard ALPA – Address can be 0 to 254. 255 means this feature is
disabled. An ALPA identifies a port in an arbitrated loop.
7. Click the Submit button to save your settings.
Port Setting Information
The table below shows the type of attached topology you will achieve based
on your connection type and the configured topology you select.
