Chapter 4: Management with WebPAM PROe
117
Shutting Down the Subsystem
To shutdown the RAID subsystem:
1. Click the Subsystem icon in Tree View.
2. Click the Administrative Tools icon.
3. Click the Shutdown link in Management View.
4. On the Shutdown or Restart tab, choose Shutdown from the Option menu.
5. Click the Submit button.
6. In the confirmation box, type the word confirm in the field provided and click
the OK button.
When the controller shuts down, your WebPAM PROe connection is lost.
7. Wait no less than two minutes.
8. Manually turn off the power supply switches on the back of the subsystem.
Monitoring the Shutdown
To monitor a shutdown, you must use the Command Line Interface (CLI) though
a serial connection to the VTrak.
Turn off both power supply switches when the following this message appears:
Shutdown complete. It is now safe to power off the subsystem.
Important
If you have a JBOD Expansion, always power off the RAID
subsystem first. Then power off the JBOD subsystems.
