VTrak E-Class Product Manual
94
Deleting an Initiator
To delete an initiator:
1. Click the Subsystem icon in Tree View.
2. Click the Administrative Tools icon.
3. Click the Storage Services icon.
4. Click the Initiators tab in Management View.
5. From the Initiators tab dropdown menu, choose Delete Initiators.
6. Check the box to the left of the initiator you want to delete.
7. Click the Submit button.
Viewing the LUN Map
To view the current LUN Map:
1. Click the Subsystem icon in Tree View.
2. Click the Administrative Tools icon.
3. Click the Storage Services icon.
4. Click the LUN Map tab in Management View.
Enabling LUN Masking
LUN masking must be enabled in order to assign LUNs to logical drives.
To enable the LUN Masking:
1. Click the Subsystem icon in Tree View.
2. Click the Administrative Tools icon.
3. Click the Storage Services icon.
4. Click the LUN Map tab in Management View.
5. Click the Enable LUN Masking box.
6. Click the Submit button.
Adding a LUN Map
You must add an initiator to the VTrak's initiator list in order to use the initiator to
create a LUN map. LUN masking must be enabled in order to assign LUNs to
logical drives.
