Chapter 4: Management with WebPAM PROe
95
To edit the LUN Map:
1. Click the Subsystem icon in Tree View.
2. Click the Administrative Tools icon.
3. Click the Storage Services icon.
4. Click the LUN Map tab in Management View and from the dropdown menu,
choose Add LUN Map.
5. Choose an initiator from the Initiator dropdown list.
Or enter the initiators name in the Initiator Name field.
Note that the initiator name you input must match exactly in order for the
connection to work.
6. In the LUN Mapping & Masking list, enter a LUN for each logical drive.
You must enter different LUN numbers for each logical drive.
7. Click the Submit button.
Editing a LUN Map
To edit the LUN Map:
1. Click the Subsystem icon in Tree View.
2. Click the Administrative Tools icon.
3. Click the Storage Services icon.
4. Click the LUN Map tab in Management View.
5. From the LUN Mapping & Masking Information list, choose an initiator and
click its link.
Or enter the initiator's name in the Initiator Name field.
Note that the initiator name you input must match exactly in order for the
connection to work.
6. In the LUN field, enter a LUN for each logical drive.
You must enter different LUN numbers for each logical drive.
7. Click the Submit button.
