RL78/G10 CHAPTER 6 TIMER ARRAY UNIT

R01UH0384EJ0311 Rev. 3.11 184

Dec 22, 2016

Figure 6-61. Example of Basic Timing of Operation as Delay Counter

TE0n

TDR0n

TCR0n

INTTM0n

0000H

a+1

b+1

FFFFH

TI0n

TS0n

Remarks 1. n: Channel number

n = 0, 1 (for 10-pin products); n = 0 to 3 (for 16-pin products)

2. TS0n: Bit n of timer channel start register 0 (TS0)

TE0n: Bit n of timer channel enable status register 0 (TE0)

TI0n: TI0n pin input signal

TCR0n: Timer count register 0n (TCR0n)

TDR0n: Timer data register 0n (TDR0n)
