RL78/G10
CHAPTER 10 A/D CONVERTER
R01UH0384EJ0311 Rev. 3.1
1
248
Dec 22, 2016
Figure 10-5. A
/D Converter Sampling and A
/D Conversion Timing
ADCS
Sampling
timing
INTAD
1 is written to ADCS.
Conversion time
Sampling
Successive conversion
Conversion standby
status
264
266
