RL78/G10 CHAPTER 2 PIN FUNCTIONS

R01UH0384EJ0311 Rev. 3.11 20

Dec 22, 2016

Figure 2-6. Pin Block Diagram for Pin Type 7-3-1

PORT

PMC

P-ch

N-ch

Pmn

P-ch

N-ch

VDD

VSS

A/D converter

PMC register

(PMCmn)

Internal bus

PU register

(PUmn)

Alternate

function

PM register

(PMmn)

Alternate

function (SAU)

Alternate function

(other than SAU )

Output latch

(Pmn)

Remarks 1. For alternate functions, see 2.1 Port Functions.

2. SAU: Serial array unit
