RL78/G10 CHAPTER 3 CPU ARCHITECTURE
R01UH0384EJ0311 Rev. 3.11 40
Dec 22, 2016
Table 3-5. Extended SFR (2nd SFR) List (1/2)
Address Special Function Register (SFR) Name Symbol R/W Manipulable Bit Range After
Reset
1-bit 8-bit
F0010H A/D converter mode register 2 ADM2 R/W
√ √
00H
F0013H A/D test register
Note 1
ADTES R/W
− √
00H
F0030H Pull-up resistor option register 0 PU0 R/W
√ √
00H
F0034H Pull-up resistor option register 4 PU4 R/W
√ √
01H
F003CH Pull-up resistor option register 12 PU12 R/W
√ √
20H
F0050H Port output mode register 0 POM0 R/W
√ √
00H
F0060H Port mode control register 0 PMC0 R/W
√ √
FFH
F0070H Noise filter enable register 0 NFEN0 R/W
√ √
00H
F0071H Noise filter enable register 1 NFEN1 R/W
√ √
00H
F0073H Input switch control register ISC R/W
√ √
00H
F0077H Peripheral I/O redirection register PIOR R/W
− √
00H
F00A8H High-speed on-chip oscillator trimming register HOCODIV R/W
− √
Undefined
Note 2
F00F0H Peripheral enable register 0 PER0 R/W
√ √
00H
F00F3H Operation speed mode control register
Note 1
OSMC R/W
− √
00H
F00FEH BCD adjust result register BCDADJ R
− √
Undefined
F0100H Serial status register 00 SSR00 R
− √
00H
F0102H Serial status register 01 SSR01 R
− √
00H
F0108H Serial flag clear trigger register 00 SIR00 R/W
− √
00H
F010AH Serial flag clear trigger register 01 SIR01 R/W
− √
00H
F0110H Serial mode register 00L SMR00L R/W
− √
20H
F0111H Serial mode register 00H SMR00H R/W
− √
00H
F0112H Serial mode register 01L SMR01L R/W
− √
20H
F0113H Serial mode register 01H SMR01H R/W
− √
00H
F0118H Serial communication operation setting register 00L SCR00L R/W
− √
87H
F0119H Serial communication operation setting register 00H SCR00H R/W
− √
00H
F011AH Serial communication operation setting register 01L SCR01L R/W
− √
87H
F011BH Serial communication operation setting register 01H SCR01H R/W
− √
00H
F0120H Serial channel enable status register 0 SE0 R
√ √
00H
F0122H Serial channel start register 0 SS0 R/W
√ √
00H
F0124H Serial channel stop register 0 ST0 R/W
√ √
00H
F0126H Serial clock select register 0 SPS0 R/W
− √
00H
F0128H Serial output register 0 SO0 R/W
− √
03H
F0129H Serial clock output register 0 CKO0 R/W
− √
03H
F012AH Serial output enable register 0 SOE0 R/W
√ √
00H
F0134H Serial output level register 0 SOL0 R/W
− √
00H
F0180H Timer counter register 00L TCR00L R
− √
FFH
F0181H Timer counter register 00H TCR00H R
− √
FFH
F0182H Timer counter register 01L TCR01L R
− √
FFH
F0183H Timer counter register 01H TCR01H R
− √
FFH
Notes 1. 16-pin products only.
2. The value after a reset is a value set in FRQSEL2 to FRQSEL0 of the option byte (000C2H).
<R>
