RL78/G10 CHAPTER 3 CPU ARCHITECTURE
R01UH0384EJ0311 Rev. 3.11 41
Dec 22, 2016
Table 3-5. Extended SFR (2nd SFR) List (2/2)
Address Special Function Register (SFR) Name Symbol R/W Manipulable Bit Range After
Reset
1-bit 8-bit
F0184H Timer counter register 02L
Note
TCR02L R
− √
FFH
F0185H Timer counter register 02H
Note
TCR02H R
− √
FFH
F0186H Timer counter register 03L
Note
TCR03L R
− √
FFH
F0187H Timer counter register 03H
Note
TCR03H R
− √
FFH
F0190H Timer mode register 00L TMR00L R/W
− √
00H
F0191H Timer mode register 00H TMR00H R/W
− √
00H
F0192H Timer mode register 01L TMR01L R/W
− √
00H
F0193H Timer mode register 01H TMR01H R/W
− √
00H
F0194H Timer mode register 02L
Note
TMR02L R/W
− √
00H
F0195H Timer mode register 02H
Note
TMR02H R/W
− √
00H
F0196H Timer mode register 03L
Note
TMR03L R/W
− √
00H
F0197H Timer mode register 03H
Note
TMR03H R/W
− √
00H
F01A0H Timer status register 00 TSR00 R
− √
00H
F01A2H Timer status register 01 TSR01 R
− √
00H
F01A4H Timer status register 02
Note
TSR02 R
− √
00H
F01A6H Timer status register 03
Note
TSR03 R
− √
00H
F01B0H Timer channel enable status register 0 TE0 R
√ √
00H
F01B1H Timer channel enable status register 0 (8-bit mode) TEH0 R
√ √
00H
F01B2H Timer channel start register 0 TS0 R/W
√ √
00H
F01B3H Timer channel start register 0 (8-bit mode) TSH0 R/W
√ √
00H
F01B4H Timer channel stop register 0 TT0 R/W
√ √
00H
F01B5H Timer channel stop register 0 (8-bit mode) TTH0 R/W
√ √
00H
F01B6H Timer clock select register 0 TPS0 R/W
− √
00H
F01B8H Timer output register 0 TO0 R/W
− √
00H
F01BAH Timer output enable register 0 TOE0 R/W
√ √
00H
F01BCH Timer output level register 0 TOL0 R/W
− √
00H
F01BEH Timer output mode register 0 TOM0 R/W
− √
00H
F0230H IICA control register 00
Note
IICCTL00 R/W
√ √
00H
F0231H IICA control register 01
Note
IICCTL01 R/W
√ √
00H
F0232H IICA low-level width setting register 0
Note
IICWL0 R/W
− √
FFH
F0233H IICA high-level width setting register 0
Note
IICWH0 R/W
− √
FFH
F0234H Slave address register 0
Note
SVA0 R/W
− √
00H
Note 16-pin products only.
Remark For SFRs in the SFR area, see Table 3-4 SFR List.
To Next Page
