RL78/G10
CHAPTER 24
ELECTRICAL SPECIFICATIONS
R01UH0384EJ0311 Rev. 3.1
1
598
Dec 22, 2016
CSI mode connection diagram
RL78
microcontroller
SCK00
SO00
SCK
SI
User's device
SI00
SO
CSI mode serial transfer timing
(When DAP0n = 0 and CKP0n
= 0, or DAP0n = 1 and CKP0n =
1.)
SI00
Input data
Output data
SO00
t
KCY1, 2
t
KL1, 2
t
KH1, 2
t
SIK1, 2
t
KSI1, 2
t
KSO1, 2
SCK00
Remark
p: CSI number
(p = 00, 01), n: Channel number (n = 0, 1)
614
616
