Print Menu (PRINT Menu) CMU
1100.4903.12 4.4 E-10
Reset
The Reset button resets all settings in the selected function groups and test modes.
A box pops up to confirm the reset. While the reset is performed, the message
Reset in progress is displayed. All running measurements are aborted and a
connection to a DUT is dropped. Then the Reset popup window is closed and the
CMU returns to the function group and test mode that was active when the reset
was initiated.
Note: A reset of the active function group is faster because no additional
software modules must be loaded. Additive function groups (e.g. an
Audio function group which complements a GSM function group) are
reset together with the selected function groups.
A reset of all instrument settings can also be performed during the
startup procedure; see Default softkey in section Startup Menu on p.
4.1 ff.
The reset button restores the default values for manual control. In
cases where the remote control commands use distinct default values
(e.g. the repetition modes) only the manual default values are
restored.
Remote control
SYSTem:PRESet[:ALL] (base system)
Compare: SYSTem:RESet[:ALL] (default parameters in remote
control, base system)
SYSTem:RESet:CURRent (default parameters in remote
control, all function groups)
Cancel
The Cancel button cancels the selection that has been made and closes the menu.
Cancel is selected by default when the Reset menu is opened.
Remote control
–
Print Menu (PRINT Menu)
The popup window Print permits to print the current screen as configured in the Print tab of the Setup
menu. It is called up on pressing the PRINT key (SYSTEM keypad).
PRINT
Fig. 4-4 Popup window Print
